24" 750mv Thermopile for Heat Glo Heatilator,Fireplace Thermopile Replacement Fireplace,Stove Accessories

Brand: palart

Features:

• *Propane gas fireplace 750 Millivolt replacement thermopile generator length 24" with aluminium glass fiber cover more durable
• *Suitable for propane gas appliances like fireplaces, hot water heater, fryer, stoves normally installed with pilot burner
• *Minium volatge 750mV but it should be heated under at least 700°C condition and raise step by step to the volatge
• *Inner resistance around 3500-4000mΩ so it needs time to heat up to 750mV

model number: 24" 750mv Thermopile

Details: Describe: *Propane gas fireplace 750 Millivolt replacement thermopile generator length 24" with aluminium glass fiber cover more durable *Suitable for propane gas appliances like fireplaces, hot water heater, fryer, stoves normally installed with pilot burner *Minium volatge 750mV but it should be heated under at least 700°C condition and raise step by step to the volatge *Inner resistance around 3500-4000mΩ so it needs time to heat up to 750mV  Working Instructions: 1. Keep the thermopile heated in the 1/3 of the head location, Don't heat the back place to heater brass sleeve. 2 Because of High Resistance inside, The thermopile need around 1-2 minutes to be heated and increase to at least 750mV ( our reset voltage is around 800-900mV) 3.Do not take it off untill you heated it around 2 minutes 4.Do not bend the fireplace thermopile too hard on the crimped part and inside wires or it may cause short circuit and low voltage problem

EAN: 8009302062886

Package Dimensions: 5.4 x 4.3 x 1.1 inches
